FUSAI standard bogie suspension purchase online for wholesale
1. 100% garments quality inspection for FUSAI drum bogie will be carried out. The inspection mainly checks if there are broken stitches, puckering, stain/dirt spot, skipped stitches, untrimmed threads, and poor washing effect. Processed by die forging and thermal treatment, the product boasts high strength and excellent stability
2. This product has a feet orthotic function, and people with plantar fasciitis or posterior tibial tendonitis will appreciate this product. This product is suited for trailers used in a wide range of industries like military transportation, engineering projects, forestry, and chemical production
3. The product can work with high accuracy. Its distinguished self-diagnostic feature can make sure that every motion is of high accuracy. The product has obtained SGS certification
4. This product stands out for its comfort. Its ergonomic design allows it significantly to stand up to the stress and impact from the feet. It is manufactured in strict accordance with TS-16949-2000 and ISO9001-2008 standards
5. This product is highly resistant to bacteria. Its fabrics have been specially treated to minimize the chance of bacterial growth. Customization based on your desired parameters is available to this product
Our bogie suspension, as a trailer suspension system, comes in various types, including high frame type, low frame type, cantilever type, and so on. It features simple, sturdy, and durable structure, and is in normal height. The low frame type suspension is suitable for normal cars, as well as high clearance vehicles due to the great stability during the braking. Besides, our technical service team can also help you choose the right model. If you need special products, our technical team will design the proper bogie suspension according to your requirements. Our annual production for suspension is 18,000 sets, which means short lead time. In the vehicle suspension industry, we have accumulated more than 10 years of experience. A complete range of production machines and testing equipment have been introduced to ensure the excellent and consistent quality of our bogie suspension.
Cantilever Bogie Suspension | ||||||||
Type of Suspension | Max.Capacity (kgs) | Spring Center(mm) | Height of pedestal(mm) | Wheel Base(mm) | Axle Model | Track(mm) | Recommended Wheel | Weight (kgs) |
FSBS24GNS1 | 24000 | 980 | 176 | 1400 | FSA12GNS3 | 1840 | 7.50V-20 | 1650 |
FSBS24GNS2 | 24000 | 980 | 176 | 1400 | FSA12GFS1 | 1870 | 8.50V-24 | 1848 |
FSBS28GNS1 | 28000 | 900 | 200 | 1550 | FSA14GNS4 | 1850 | 8.00V-20 | 1765 |
FSBS28GNS2 | 28000 | 900 | 200 | 1550 | FSA14GFS1 | 1840 | 8.50V-24 | 1905 |
| FSBS32GNS1 | 32000 | 900 | 200 | 1550 | FSA16GNS2 | 1840 | 8.50V-20 | 1825 |
| FSBS32GNS2 | 32000 | 900 | 200 | 1550 | FSA16GFS1 | 1850 | 8.50V-24 | 1961 |
| FSBS36GNS3 | 36000 | 900 | 233 | 1550 | FSA18GNS1 | 1850 | 8.50V-20 | 1886 |
◪ 1.Central axle pedestal
The central axle is made of premium low alloy seamless steel pipe, and processed by tempering and various high precision processing techniques. Thus the axle’s strength is greatly enhanced. The panel is made of high-strength low alloy steel plate by punch forming technique, so it is strong and durable. Other supporting accessories are all welded by high-strength low alloy plate. The central axle pedestal comes with stiffening girder in it, making the whole structure of our bogie suspension highly resistant to the twisting force and bending force.
◪ 2. Central bearing pedestal
The anti-wear sliding bearing (with copper bush) embedded design is adopted. Thus the central axle and the bearing are more stable and have longer service life.
◪ 3.Leaf spring pedestal
The nodular cast iron is used for the leaf spring pedestal of our bogie suspension to make it more anti-wear and impact resistant. The coupler between leaf spring pedestal and leaf spring assembly comes in rubber inner-bushing and separating design, which can effectively lower the abrasion coefficient between the leaf spring and spring pedestal, and make the service life of the two components longer.
◪ 4. Leaf spring
The leaf spring is made of high-strength alloy leaf spring, and processed by advanced European processing techniques. The spring of our bogie suspension features high strength, great durability and is highly interchangeable.
◪ 5. Simple structure
Our bogie suspension has a simple and compact structure. It mainly comprise of five components, including Central axle pedestal, central bearing pedestal assembly, leaf spring pedestal assembly, leaf spring pedestal, and axel. It is mounted onto the suspension by bolted connection, making the later maintenance and repairing quite simple and convenient.
◪ 6.The bogie suspension has low requirements for the road surface because of its great adaptability.
Company Features
1. Shandong Fuhua Axle Co., Ltd is a technologically advanced factory in the bogie suspension field. Shandong Fuhua Axle Co., Ltd has successfully got several patents for technology.
2. Quality is above everything in Shandong Fuhua Axle Co., Ltd.
3. The standard nature of these processes permits us to fabricate drum bogie . All of our business activities will comply with regulations stipulated in the Environmental Protection Act. We have introduced waste treatment facilities that are appropriately licensed for either storing, recycling, treating or disposing of the waste.
