cantilever rear suspension for merchant FUSAI
1. This high-grade FUSAI cantilever kit provides professional and attractive design.
2. Such design ensures cantilever rear suspension has some necessary characters such as cantilever kit .
3. Based on the core of cantilever kit , it is clear that cantilever rear suspension made in FUSAI is a new trend.
4. It's simple to work and the buttons just need a light touch. And it is pretty much silent. - One of our customers said.
The cantilever suspension is mainly used as the connecting parts between trailer axle and suspension. Generally, anti-wear sliding bearings (with copper bush or cast iron bush), instead of leaf springs, are used as the couplers and supporting devices. It is mainly used as super heavy duty suspension for lowbed trailer. Our cantilever suspension works well on very rough ground for hauling heavy loads. The specially designed components and low abrasion wiggling suspension pedestal can guaranteed the good transverse and longitude axle compensation on bad road conditions. This kind of trailer suspension has been widely used in many fields like military industry, engineering project, forestry, oil industry, chemical production, and so on. Our technical team can design and manufacture custom cantilever suspension according to your application.
Three-Axle Cantilever Suspension | |||||||||||||||||
Model | Central Distance(mm) | Rated Load(kg) | Track(mm) | Wheel Base(mm) | Total Width(mm) | B(mm) | E(mm) | F(mm) | Central Height(mm) | F&B Swing | L&R Swing | Brake Size | Wheel Fixing | Tyre | |||
Type | P.C.D | H | Stud | ||||||||||||||
FSCS100ANS1 | 1800 | 100000 | 965 | 1220 | 3385 | 220 | 1320 | 1090 | 180-340 | 7° | 5° | Φ420×180 | 7.5-20 | Φ335 | Φ281 | 10－M22×1.5 ISO | 10.00-15 |
FSCS100ANS2 | 1600 | 100000 | 900 | 1320 | 3000 | 200 | 1220 | 990 | 180-340 | 7° | 5° | Φ420×180 | 6.5-20 | Φ335 | Φ281 | 10－M22×1.5 ISO | 8.25-20 |
FSCS100ANS3 | 1730 | 100000 | 940 | 1320 | 3260 | 200 | 1320 | 1090 | 180-340 | 7° | 5° | Φ420×180 | 67.5-20 | Φ335 | Φ281 | 10－M22×1.5 ISO | 9.00-20 |
| FSCS150ANS1 | 1935 | 150000 | 1055 | 1320 | 3650 | 220 | 1320 | 1090 | 220-380 | 7° | 5° | Φ420×220 | 8.5-20 | Φ335 | Φ281 | 10－M22×1.5 ISO | 12.00-20 |
◪ 1.The suspension is made from durable parts. Our efficient quality control system can ensure that our products can work normally even in very bad working conditions.
◪ 2.Excellent maneuverability is available for our cantilever suspension.
◪ 3.The well designed spinning suspension pedestal has ensured the excellent height difference on cross-country conditions.
◪ 4.We can provide custom trailer suspension solution according to your requirements. Just contact us at any time.
Company Features
1. FUSAI has deeply grasped the precious chance to grow in the industry.
2. The strong R&D team guarantees the high-quality products of Fuhua Trailer Parts.
3. Better quality and service for cantilever rear suspension is what we are pursuing. Contact us! Shandong Fuhua Axle Co., Ltd will step up efforts to open up overseas aftermarket and provide customers with the most cost-effective cantilever suspension kit . Contact us! Shandong Fuhua Axle Co., Ltd's mission is to provide innovative cantilever suspension designed to exceed customer expectations. Contact us!
